tempusSystem Class JitterTimeHistory

JitterTimeHistory is part of the WaveTrain system class library Parameters tv   Vector<float>    Time vector    Vector() vx   Vector<float>    X signal vector    Vector() vy   Vector<float>    Y signal vector    Vector() t0   float    The time within the tv vector that is to correspond to simulation time 0.    0.0 vx0   float    Initial x signal value    0.0 vy0   float    Initial y signal value    0.0 sampleFlag   int    If 0, use linear interpolation, otherwise use sample and hold.    0 timeLimit   double    Maximum amount of time for which vector will be stored (if zero, then all input vectors are stored)    0.0 applyToField   bool    if true, tilt is put into complex field, rather than reference wave    false Inputs incomingIncident   WaveTrain    describes all light incident from the "incoming" direction    WaveTrain() outgoingIncident   WaveTrain    describes all light incident from the "outgoing" direction    WaveTrain() Outputs incomingTransmitted   WaveTrain    describes all light transmitted in the "incoming" direction  WaveTrain()   outgoingTransmitted   WaveTrain    describes all light transmitted in the "outgoing" direction  WaveTrain()   Subsystems   Tilt    tilt applyToField   bool    applyToField   TimeHistory2    timehistory2 tv   Vector<float>    tv vx   Vector<float>    vx vy   Vector<float>    vy t0   float    t0 vx0   float    vx0 vy0   float    vy0 sampleFlag   int    sampleFlag timeLimit   double    timeLimit Connections tilt.incomingIncident   <<=   incomingIncident tilt.outgoingIncident   <<=   outgoingIncident incomingTransmitted   <<=   tilt.incomingTransmitted outgoingTransmitted   <<=   tilt.outgoingTransmitted tilt.tilt   <<=   timehistory2.rv Last Saved: Thu Oct 03 14:55:29 MDT 2002 by TVE version 2007B
