tempusSystem Class PointReflector

PointReflector is part of the WaveTrain system class library Parameters wavelength   float    Wavelength of source (m)    1.0e-06 power   float    Source power (W)    1.0e+06 exposureInterval   float    Interval between pulses (s)    1.0e-03 exposureLength   float    Length of pulse (s)    1.0e-06 nxy   int    Number of pixels across sensor    64 dxy   float    Width of sensor (m)    1.0 r0   Vector<float>    Initial point source position (m,m)    ZeroVecF(2) radius   float    Radius of reflection (m)    0.5 targetGrid   GridGeometry    defines propagation mesh at aperture plane.    grid_with_origin_on_mesh(propnxy,propdxy) superApDiameter   float    Used in modeling point sources and surface speckle; defines a circular region at the aperture plane which in vacuum would be uniformly illuminated    superApDiameter edgeSigma   float    Used in modeling point sources and surface speckle; defines a gaussian round odd at the edge of the superaperture    edgeSigma Inputs incident   WaveTrain    Incident Wavetrain to be sampled    WaveTrain() pson   bool    Flag indicating whether or not the point source is on    false tbon   bool    Flag indicating whether or not the sensor is on    false Outputs transmitted   WaveTrain    Describes all light transmitted in the "incoming" direction     Subsystems   TargetBoard    targetboard wavelength   float    wavelength nxy   int    nxy dxy   float    dxy   FpaProcessing    fpaproc nx   int    nxy ny   int    nxy dx   float    dxy dy   float    dxy relativeThreshold   float    0.0 typeOfThreshold   int    1 n_per_average   int    0   MovingPointSource    mps wavelength   float    wavelength power   float    power r0   Vector<float>    r0   FtoVF    ftovf   Aperture    aperture apertureRadius   float    radius annulusRadius   float    0.0   PropagationController    propagationcontroller targetGrid   GridGeometry    targetGrid xReferenceFocus   float    0.0 yReferenceFocus   float    0.0 oneTimeSpatialFilter   constFilter&    NullFilter() spatialFilter   constFilter&    NullFilter() absorbingBoundary   constFilter&    NullFilter() pointSourceModel   PointSourceModel    DEFAULT_PSM speckleModel   SpeckleModel    DEFAULT_SM superApDiameter   float    superApDiameter edgeSigma   float    edgeSigma useDispersion   bool    false nominalWavelength   float    0.0 Connections targetboard.incident   <<=   incident mps.on   <<=   pson targetboard.on   <<=   tbon transmitted   <<=   aperture.incomingTransmitted fpaproc.image   <<=   targetboard.integrated_intensity ftovf.f0   <<=   fpaproc.xc ftovf.f1   <<=   fpaproc.yc mps.r   <<=   ftovf.vout aperture.incomingIncident   <<=   propagationcontroller.transmitted propagationcontroller.incident   <<=   mps.transmitted Last Saved: Fri Feb 22 09:11:27 MST 2008 by TVE version 2007B
